NT1167 - Rear axle sleeve
Fitted to the following tractors:
Nuffield M4, PM4, DM4, 4DMÂ Gearbox number 1 - 17507, U17508-34909
See ATJ7056 for later models
Important
Check size of sleeve before ordering.
Sleeve outside diameter 3"Â (76.22mm)
Sleeve length 34.64mm long
Rear axle sleeve, note this part requires heating to fit (see workshop manual for instructions).
For rear axle seals see part no NT3076
See extra information tab for fitting instructions.
Original equipment manufacturers names and parts numbers are quoted for reference purposes only and are not intended to suggest that our replacement parts are made by the original equipment manufacturer.
Product images are for illustrative purposes only and may not always be an exact representation of the product.
Removing the old sleeve from the axle we heat the sleeve with the gas bottle unit cherry red and it will drop off.
Then allow the half to cool and clean the journal where the sleeve fits with emery cloth.
Fitting the new sleeve you need to heat to a dark straw colour uniformly (all over), a tip we use is to place the sleeve on steel plate (heavy 3/8" 10mm) and heat the plate with gas bottle on the underside (this should git a more uniform heat distribution all over the new sleeve).
Stand the half shaft on the floor and drop the heated over the shaft, it should fall in to place and then cool and shrink to the shaft.
