Layshaft fitted to the Nuffield models with 5 speed gear box and single clutch after serial 1001.
Fitted to the Nuffield 3DL, 4DM, 342 and 460 models.
Gear details -
Thread diameter 44.5mm (1.750")
Main spline 50mm with 6 splines
16 teeth at a diameter 68.8mm (2.709")
Rear spline 34.95mm with 6 splines, with 15.6mm bush in end
Overall length 510mm (20.078")
