CTJ8260 - Heavy duty 11" diameter clutch plate with a centre shaft size x 1 1/8" and 10 splines. Asbestos free.
Fitted to Leyland, Marshall tractors with a dual clutch assembly (independent PTO clutch plate).Â
Note: Heavy duty grooved linings. Plate thickness when new 8.5mm
Fitted to the following tractors:
Leyland 344, 384, 253, 245, 255, 270, 262, 462, 272, 472, 282, 482
Leyland 502, 602, 604, 702, 704, 802, 804
Marshall 502, 602, 604, 702, 704, 802, 804Â
Note JCB part number 02350041
Original equipment manufacturers names and parts numbers are quoted for reference purposes only and are not intended to suggest that our replacement parts are made by the original equipment manufacturer.
Product images are for illustrative purposes only and may not always be an exact representation of the product.
Please open these links for fitting pictures
Important: the centre drive boss of the plate should project out on each side of the plate, other suppliers will offer a David Brown clutch plate instead which will have a boss that only projects (sticks out) on one side. Warning these plates will fail prematurely.
