ATJ5724 - Pick up hitch - frame pivot bolt

£19.50 exc VAT

Need it delivering elsewhere? Click here

Delivery Information Returns Information

ATJ5724 - Pick up hitch pivot shoulder bolt. Located under the tractor where the fixed and moving frames meet.
This bolt has a 3/4" UNF thread like the original bolts. Finished in BZP (Bright zinc plate silver) not gold as in the picture.

Diameter of journals are 25.4mm 1" and 22mm 7/8"

Fitted to the following tractors :
Nuffield 3/45, 4/65
Leyland 344, 384, 253, 245, 255, 270, 262, 462, 272, 472, 282, 482
Leyland 285, 485, 2100, 4100 tractors fitted with A.R.M. pick-up hitch
Leyland 502, 602, 604, 702, 704, 802, 804 from tractor serial number C250840 to 251901
Marshall 502, 602, 604, 702, 704, 802, 804 from tractor serial number C250840 to 251901

Original equipment manufacturers names and parts numbers are quoted for reference purposes only and are not intended to suggest that our replacement parts are made by the original equipment manufacturer.

Product images are for illustrative purposes only and may not always be an exact representation of the product.

Note:

Use nut LNZ412 and washer WL600121 with this bolt.
