ATJ1024 - Rear axle seal kit. ALWAYS CHECK SIZES BEFORE PLACING AN ORDER. Seal outside diameter is 111.12mm (4.3/8")
Kit contains 2 x ATJ1024 seal & 1 x NT7183 felt seal & 1 x GHF513 Split pin (item 7 in diagram)
This is a kit for one side of the tractor. 2 kits required per tractor.
The following gaskets are used when replacing the rear axle seal kits. These can be ordered seperately.
ATJ5622 Axle housing end cap gasketÂ
ATJ5630 Hydraulic back casting gasket
Fitted to the following tractors:
Nuffield PM4 and M4 - 2nd type later models (1-34910 on, INPT101 on, 4010-501 on, 4013-501 on)
Nuffield 3DL, 4DM, 342, 460, 10/42, 10/60, 3/45, 4/65 with standard axle.
Nuffield 3DL, 4DM, 342, 460 fitted to some later tractors with sliding hub type axles. CHECK SIZES BEFORE PLACING AN ORDER
Nuffield 10/42, 10/60, 3/45, 4/65Â with sliding hub type axles.
Leyland 344, 384, 253, 245, 255, 270, 262, 462, 272, 472, 282, 482 with both standard axle and sliding hub type axle.
Marshall 502, 602, 604, 702, 704, 802, 804, 904XL, 954XLÂ with both standard axle and sliding hub type axle.
Original equipment manufacturers names and parts numbers are quoted for reference purposes only and are not intended to suggest that our replacement parts are made by the original equipment manufacturer.
Product images are for illustrative purposes only and may not always be an exact representation of the product.
When changing these oil seals you must ensure that the sleeve the seals run on have no grooves or pits on the surfaces. If there is any surface damage then the sleeves must be replaced, otherwise they will not seal.
See items 3 and 7 on diagram
