Marshall Tractors

96K471 - Piston & ring set (98mm)

  • Brand: Marshall Tractors
  • Condition: New
  • Part Number: 96K471
In Stock Out of Stock Awaiting
Usually Dispatched Next Working Day
£59.90 exc VAT

Need it delivering elsewhere? Click here


96K471 - Piston and ring set - including gudgeon pin and clips.

This 4 ring piston is fitted to the Marshall tractors with the 4/98 engine (also fitted to the Leyland 282 and 482 with turbocharged engines)


If you are unsure if this is the correct piston for your engine then please get in touch with your engine serial number and we can help you.

This set is made up of part numbers 96K471 and AHM9072


Technical Details

Crown diameter 97.510 mm 3.839 in
Compression height 68.170 mm 2.684 in
Overall height 116.330 mm 4.58 in
Chamber diameter 56.030 mm 2.206 in
Chamber depth 24.790 mm 0.976 in
Piston pin diameter 36.51mm 1.437 in
Number of rings 4

Old part number 96K465

JCB part no 02300300

Original equipment manufacturers names and parts numbers are quoted for reference purposes only and are not intended to suggest that our replacement parts are made by the original equipment manufacturer.

Product images are for illustrative purposes only and may not always be an exact representation of the product.

Note:

These pistons have a larger gudgeon pin 36.51mm, consequently cannot be fitted instead to 96K570 (which has a gudgeon pin diameter of 34.925mm)
