7H6032 - Shim 0.010" - Steering box shim
Hole centres 53mm, hole diameter 8.4mm, large hole through centre 57.5mm.
Note: Add shims between the outer tube and the housing, until end float is eliminated in the steering column shaft.
Any combination of shim thickness can be used to achieve this (see 7H6000, 7H6031)
Fitted to the following tractors:
BMC Mini
Nuffield 4/25, 3/45, 4/65
Leyland 154, 344, 384, 253, 245, 255, 270, 262, 272
See items 17 and 8 on diagrams
See 7H6034 for gasket
