37D2943 - Liner for BMC 3.4TD and 5.1VD engines.
Fitted the following tractors:
Leyland 344
Also fitted to BMC 5.1VD lorry engines.
Bore Size 95.046mm
Flange Diameter 117.07
Flange Height 8.890
Outside diameter where the liner seal contacts the liner 110.60mm
Overall Height 221.57
Original equipment manufacturers names and parts numbers are quoted for reference purposes only and are not intended to suggest that our replacement parts are made by the original equipment manufacturer.
Product images are for illustrative purposes only and may not always be an exact representation of the product.
-Use the following liner shims for this liner:
89J88 (0.003")
89J89 (0.004")
89J90 (0.005")
-Fit with liner seal part no 37D1857 (not included with liner)
37D976 Piston
AHM9023 Piston rings
Important always check liner sizes before ordering,
if unsure please ring us for advice.
